LCD Panel

• Panel Size ( diagonal ) 17.3-inch Widescreen TFT color LCD
• Display pixel ( dots x lines ) 1920 x 1080
• Brightness ( typ. ) 400
• Contrast Ratio ( typ. ) 600:1
• Color 16.7 M, 8-bit
• Viewing Angle ( L/R/U/D ) 80/80/60/80
• Response Time ( ms ) 40 Dot pitch ( mm ) 0.1989
• Display Area ( mm ) 381.888H x 214.812V
• Surface treatment Anti-glare, Hard-coating Surface hardness 3H
• Backlight Type LED
• MTBF ( hrs ) 50,000

Power

Power Supply

• Range Auto-sensing 100 to 240VAC, 50 / 60Hz

Power Consumption

• Screen ON Max. 25W
• Power saving mode Max. 4W
• Power button OFF Max. 1W

Environmental Conditions

Operating

• Temperature 0 to 55°C degree
• Humidity 20~90%, non-condensing
• Altitude 16,000 ft

Storage / Non-operating

• Temperature -20 to 60°C degree
• Humidity 5~90%, non-condensing
• Altitude 40,000 ft
• Shock 10G acceleration (11ms duration)
• Vibration 5~500Hz 1G RMS random

Physical Specification

• Product ( W x D x H ) 480 x 48 x 266 mm 18.9 x 1.9 x 10.5 inch
• Packing ( W x D x H ) 529 x 124 x 451 mm 20.8 x 4.9 x 17.8 inch
• Net Weight 4.5 kgs / 9.9 lbs
• Gross Weight 6 kgs / 13.2 lbs

Regulatory

• Safety FCC & CE certifi ed
• Environmental RoHS2 & REACH compliant
