LCD Panel

• Panel Size ( diagonal ) 21.5-inch Widescreen TFT color LCD
• Display pixel ( dots x lines ) 1920 x 1080
• Brightness ( typ. ) 250
• Contrast Ratio ( typ. ) 1000:1
• Color 16.7 M
• Viewing Angle ( L/R/U/D ) 85/85/80/80
• Response Time ( ms ) 5
• Dot pitch ( mm ) 0.248
• Display Area ( mm ) 476.64H x 268.11V
• Surface treatment Haze 25%, Hard-coating Surface hardness 3H
• Backlight Type LED
• MTBF ( hrs ) 30,000

Video Connectivity

Digital

• HDMI HDMI 1.3, CEA-861-D
• Displayport

Analog

• VGA Analog 0.7Vp-p

• Plug & Play DVI / VGA VESA EDID structure 1.3
• Synchronization VGA Separate, Composite & SOG

Audio Connectivity

• Audio Input Connector 3.5mm stereo jack
• Impedance / Power level 30kΩ / 750mV

Audio Output

• Connector 3.5mm stereo jack
• Resistance / Power level 30kΩ / 2.8V

Speaker

• Dual Stereo Speaker 2W x 2

Environmental Conditions

Operating

• Temperature 0 to 55°C degree
• Humidity 20~90%, non-condensing
• Altitude 16,000 ft

Storage / Non-operating

• Temperature -20 to 60°C degree
• Humidity 5~90%, non-condensing
• Altitude 40,000 ft
• Shock 10G acceleration (11ms duration)
• Vibration 5~500Hz 1G RMS random

Power

• Power Supply Range Auto-sensing 100 to 240VAC, 50 / 60Hz

Power Consumption

• Screen ON Max. 32W
• Power saving mode Max. 4W
• Power button OFF Max. 1W

Physical Specification

• Product ( W x D x H ) 501.9 x 64 x 353 mm 19.8 x 2.5 x 13.9 inch
• Packing ( W x D x H ) 585 x 124 x 557 mm 23 x 4.9 x 21.9 inch
• Net Weight 10.3 kgs / 22.7 lbs
• Gross Weight 12.7 kgs / 27.9 lbs

Regulatory

• Safety FCC & CE certifi ed
• Environmental RoHS2 & REACH compliant
