CPU-1200-PDC-G6405
Intel G6405 - 4.1GHz - 2 core - 4 threads, 4MB Cache - UHD Graphics 610 (58W)
CPU Specifications
Total Cores - 2
Total Threads - 4
Processor Base Frequency - 4.10 GHz
Cache - 4 MB Intel® Smart Cache
Bus Speed - 8 GT/s
TDP - 58 W
CPU Specifications
Total Cores - 2
Total Threads - 4
Processor Base Frequency - 4.10 GHz
Cache - 4 MB Intel® Smart Cache
Bus Speed - 8 GT/s
TDP - 58 W
Supplemental Information
Marketing Status - Launched
Launch Date - Q1'21
Embedded Options Available - No
Use Conditions - PC/Client/Tablet
Memory Specifications
Max Memory Size (dependent on memory type) - 128 GB
Memory Types - DDR4-2666
Max # of Memory Channels - 2
Max Memory Bandwidth - 41.6 GB/s
GPU Specifications
GPU Name‡ - Intel® UHD Graphics 610
Graphics Base Frequency - 350 MHz
Graphics Max Dynamic Frequency - 1.05 GHz
Graphics Video Max Memory - 64 GB
4K Support - Yes, at 60Hz
Max Resolution (HDMI)‡ - 4096x2160@30Hz
Max Resolution (DP)‡ - 4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡ - 4096x2304@60Hz
DirectX* Support - 12
OpenGL* Support - 4.5
Intel® Quick Sync Video - Yes
Intel® InTru™ 3D Technology - Yes
Intel® Clear Video HD Technology - Yes
Intel® Clear Video Technology - Yes
# of Displays Supported ‡ - 3
Device ID - 0x9BA8
Expansion Options
Scalability - 1S Only
PCI Express Revision - 3.0
PCI Express Configurations ‡ - Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes - 16
Package Specifications
Sockets Supported - FCLGA1200
Max CPU Configuration - 1
Thermal Solution Specification - PCG 2015C
TJUNCTION - 100°C
Package Size - 37.5mm x 37.5mm
Advanced Technologies
Intel® Optane™ Memory Supported ‡ - Yes
Intel® Thermal Velocity Boost - No
Intel® Turbo Boost Max Technology 3.0 ‡ - No
Intel® Turbo Boost Technology ‡ - No
Intel® Hyper-Threading Technology ‡ - Yes
Intel® Transactional Synchronization Extensions - No
Intel® 64 ‡ - Yes
Instruction Set - 64-bit
Instruction Set Extensions - Intel® SSE4.1, Intel® SSE4.2
Idle States - Yes
Enhanced Intel SpeedStep® Technology - Yes
Thermal Monitoring Technologies - Yes
Intel® Identity Protection Technology ‡ - Yes
Security & Reliability
Intel® AES New Instructions - Yes
Secure Key - Yes
Intel® Software Guard Extensions (Intel® SGX) - Yes with Intel® ME
Intel® OS Guard - Yes
Intel® Trusted Execution Technology ‡ - No
Execute Disable Bit ‡ - Yes
Intel® Boot Guard - Yes
Intel® Stable IT Platform Program (SIPP) - No
Intel® Virtualization Technology (VT-x) ‡ - Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ - Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ - Yes
