CPU-1200-XEON-E-2388G

CPU Specifications
Total Cores - 8
Total Threads - 16
Max Turbo Frequency - 5.10 GHz
Intel® Turbo Boost Technology 2.0 Frequency‡ - 5.10 GHz
Processor Base Frequency - 3.20 GHz
Cache - 16 MB Intel® Smart Cache
Bus Speed - 8 GT/s
TDP - 95 W

Supplemental Information
Marketing Status - Launched
Launch Date - Q3'21
Servicing Status - Baseline Servicing
Embedded Options Available - No
Use Conditions Server/Enterprise

Memory Specifications
Max Memory Size (dependent on memory type) - 128 GB
Memory Types - DDR4-3200
Max # of Memory Channels - 2
Intel® Optane™ Persistent Memory Supported - No
ECC Memory Supported ‡ - Yes

GPU Specifications
GPU Name‡ - Intel® UHD Graphics P750
Graphics Base Frequency - 350 MHz
Graphics Max Dynamic Frequency - 1.30 GHz
Graphics Video Max Memory - 64 GB
Execution Units - 32
4K Support - Yes, at 60Hz
Max Resolution (HDMI)‡ - 4096 x 2160 @60 Hz
Max Resolution (DP)‡ - 5120 x 3200 @ 60 Hz
Max Resolution (eDP - Integrated Flat Panel)‡ - 5120 x 3200 @ 60 Hz
DirectX* Support - 12.1
OpenGL* Support - 4.5
Intel® Quick Sync Video - Yes
Intel® InTru™ 3D Technology - Yes
Intel® Clear Video HD Technology - Yes
Intel® Clear Video Technology - Yes
# of Displays Supported ‡1
Device ID - 0x4C9A

Expansion Options
Scalability - 1S Only
PCI Express Revision - 4.0
Microprocessor PCIe Revision Gen - 4
PCI Express Configurations ‡ - Up to 1x16+1x4, 2x8+1x4, 1x8+3x4
Max # of PCI Express Lanes - 20

Package Specifications
Sockets Supported - FCLGA1200
Max CPU Configuration - 1
TJUNCTION - 100 °C
Package Size - 37.5 mm x 37.5 mm

Advanced Technologies
Intel® Turbo Boost Technology ‡ - 2.0
Intel® Hyper-Threading Technology ‡ - Yes
Intel® Transactional Synchronization Extensions - No
Intel® 64 ‡ - Yes
Instruction Set - 64-bit
Instruction Set Extensions - Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512
Idle States - Yes
Enhanced Intel SpeedStep® Technology - Yes
Thermal Monitoring Technologies - Yes

Security & Reliability
Intel vPro® Eligibility ‡ - Intel vPro® Platform
Intel® AES New Instructions - Yes
Secure Key - Yes
Intel® Software Guard Extensions (Intel® SGX) - Yes with Intel® SPS
Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX - 0.5 GB
Intel® Memory Protection Extensions (Intel® MPX) - Yes
Intel® OS Guard - Yes
Intel® Trusted Execution Technology ‡ - Yes
Execute Disable Bit ‡ - Yes
Intel® Boot Guard - Yes
Intel® Virtualization Technology (VT-x) ‡ - Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ - Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ - Yes
