SL-EB-ICO300-2-83B This item is no longer available.
Microbox PC - Embedded PC featuring Long Production Cycle Motherboard (Through Q1 2031) with Intel Celeron SoC, Intel Celeron N3350 processor (1.1 GHz Dual Core, Burst 2.40GHz) Intel® HD Graphics 500, TDP 6W, 2x 1GbE (10/100/1000) LAN, WIFI,2x Serial, Up to 8GB RAM, Dimensions of Enclosure: 4.33"L x 1.88"W x 6.10"H, Power Supply Power Input Range: 12 - 24 VDC. Power Protection: DC Version, OVP, Reverse protection.
Standard Lead Time 4 Weeks.
Type:
- Microbox PC
- Dimension: 4.33" x 1.88" x 6.10"
Motherboard:
- Featuring Intel Celeron SoC and Intel Celeron N3350 processor (1.1 GHz Dual Core, Burst 2.40GHz) Intel® HD Graphics 500, TDP 6W
- Long Production Cycle Motherboard (Through Q1 2031)
- LAN: 2x Ports (1GbE (10/100/1000))
- WiFi: Wireless antennas pre-assembled
- Video: VGA
- Audio: No Onboard Audio
- Ports:
2x COM Port (RS232/422/485 Rear)
See specifications for more ports - Operating Temperature: -20ºC to 70ºC (-4ºF to 158ºF)
Also Included:
- Memory: 2GB DDR3L 1600MHz SODIMM RAM (Not Recommended - Use with Embedded Operating System Only)
- Hard Drive: 120GB SSD SATA 6.0Gb/s, 500/320MB/s read/write (or greater)
- Power Supply: Power Input Range: 12 - 24 VDC. Power Protection: DC Version, OVP, Reverse protection
- Operating System: Not Included - See options below
- Warranty: One-Year Depot Warranty
MotherBoard Specifications:
- Motherboard Model
- Motherboard Type: Embedded
- Long Production Cycle
- Long Life: YES
- EOL Date: Q1 2031
- Fanless
- Supported CPU
- Number of Processors: 1
- Processor Type: Embedded CPUs (ultra-low power, soldered down)
- Embedded CPU: Intel Celeron N3350 processor (1.1 GHz Dual Core, Burst 2.40GHz) Intel® HD Graphics 500, TDP 6W
- Chipset
- Chipset: Intel Celeron SoC
- Memory
- Memory Type: SO DIMM DDR3 1600MHz
- Memory Type: Non-ECC
- DIMMS: 1
- Maximum Memory: 8GB
- On Board Audio
- Audio Type: No Onboard Audio
- On Board Video
- Video Chipset: Supported by CPU - see Embedded CPU Information
- Video on IO: VGA
- VGA Port Out: 1
- LAN
- LAN Ports: 2
- LAN Type: 1GbE (10/100/1000)
- LAN Chipset: Intel® i211AT
- Second LAN Chipset: Intel® i211AT
- Wireless LAN: Wireless antennas pre-assembled
- Drive Interface
- SATA III Ports (6GB): 1
- Expansion Slots
- mini PCIe
- mSATA
- USB and PCIe signals (Internal)
- half and/or full size mini PCIe card: full size
- Second mini PCIe
- USB and PCIe signals (Internal)
- half and/or full size mini PCIe card: full size
- Rear IO
- Serial 232/422/485 Ports: 2
- Digital I/O (8 Bit)
- Management Features
- Watch Dog
- Environmental
- Operating Temperature: -20ºC to 70ºC (-4ºF to 158ºF )
- High Humidity: 95%
- Low Humidity: 10%
- Operating System Support
- Windows 10 Home (64 Bit)
- Windows 10 Pro (64-Bit)
- Windows 10 IoT Entry
- Windows 10 IoT Entry 2019 LTSC
- Compliance of Component
- CE
- FCC
- Warranty of Component
- Motherboard Warranty: 1 Year
Chassis Specifications:
- General
- Form Factor: Micro PC
- Color: Black
- Material: Extruded Aluminum and Heavy-duty Steel
- Material Thickness: 1mm
- Slide Rails: Optional
- Expansion
- Internal 2.5" Bays: 1
- Front Ports
- USB 3.2 Ports (Front): 4
- Physical
- Depth: 4.33"
- Width: 1.88"
- Height: 6.10"
- Shipping Box - Depth: 7.70"
- Shipping Box - Width: 6.50"
- Shipping Box - Height: 4.30"
- Shipping Weight: 4lbs
- Power
- Built-in Chassis Power Supply: Power Input Range: 12 - 24 VDC. Power Protection: DC Version, OVP, Reverse protection
