SL-MOBILE-GT78V8 This item is no longer available.
8" TFT color LCD 1280x800 WXGA resolution with P-cap Multi-Touch..Embedded 1D/2D barcode imager and 5MP front camera and 13MP AF rear camera with flashlight, High mobility with multiple-connectivity including WLAN
-
8" TFT color LCD 1280 x 800 WXGA resolution with P-cap Multi-Touch
-
Embedded 1D/2D barcode imager and 5MP front camera and 13MP AF rear camera with flashlight
-
Field replaceable battery with optimized battery life up to 8 hours
-
High mobility with multiple-connectivity including WLAN and WWAN
-
MIL-STD-810G compliant, 1.2m (4ft.) drop resistance
-
Fully rugged IP65 enclosure to protect from dust and water
-
Node-Watch supported to unified manage mobile devices, apps, and contents
System
CPU Quad Core ARM Cortex-A53 1.3GHz
OS Android™ 7.0
Memory 3GB LPDDR2
Flash 16 GB eMMC (32 GB option)
LCD Display
Size/Type 8” TFT LCD
Resolution 1280 x 800
Brightness 400 nits
Touch Screen 5-point capacitive touch (PCT)
Peripherals and Devices
Camera
- Front: 5M
- Rear: 13M AF with Flashlight
Sensor
- Magnetometer (M-Sensor/E-Compass)
- Accelerometer (G-sensor)
- Gyroscope
- Ambient light sensor
- Barometer
Barcode Scanner 2D barcode reader (N6603), w/ physical trigger button
Audio & Vibrator
- 1 x built-in microphone
- 1 x built-in speaker (1.5W)
- 1 x vibrator
Wireless
WLAN IEEE 802.11 a/b/g/n
WWAN (ME909s-120) Optional 1
- 2G GSM/GPRS/EDGE (Band 850 / 900 / 1800 / 1900)
- 3G WCDMA (Band 1,2,5,8)
- LTE (Band 1,2,3,4,5,7,8,20)
WWAN (NL-SWLTES7588-Verizon) Optional 2
- 3G WCDMA (Band 2,5)
- LTE (Band 2,4,5,12,13,17)
Navigation
- GPS/Glonass
- GPS/Beidou (Option)
NFC
- ISO 15693 ; ISO 14443A ; ISO 14443B, B’ ;
- ISO 18000-3 ; NFC Forum Type1-4 Tag ; Kovio
I/O Interface
USB Port 1 x micro USB 2.0 port High Speed/ OTG Compatible
SD Slot 1 x microSD card slot (max 64G)
SIM Socket 1 x micro-SIM (3FF) socket supporting 2G/ 3G/ LTE
Pogo pin Extra power pins for vehicle bracket; 5V/2A*
* For USB charging, the GT-78V can use 9V/2A and 5V/2A USB charger adapter. For pogo pin, the charge voltage is 5V/2A only.
Power Supply
Battery Type Lithium-ion rechargeable battery, field replaceable.
Battery Capacity Typical 3.7V, 6200mAh
Adapter
Adapter Input AC 100~240V 50~60 Hz
Adapter Output 9V/2A, 5V/2A
Mechanical
Dimensions (W x H x D) 220 x 147 x 20.9 mm
Weight 550g (1.22lb) (with battery)
Ingress Protection IP65, 1.2m drop
Environmental
Operating Temp. -10°C ~ 55°C (14°F ~ 131°F )
Storage Temp. -20°C ~ 65°C (-4°F ~ 149°F)
Operating Humidity 5% ~ 95% RH
Packing Information
Rechargeable Li-ion battery pack 1 x Typical 3.8V, 6200mAh
User Cable 1x 1m1
