SL-RACK-ST-RK1224WALHM
12U Wall-Mount Server Rack Cabinet - 19.7 in. Deep - Hinged
Required LTL Feight Shipping. Please contact sales for a shipping quote.
- Save space by wall-mounting your servers or networking equipment
- Hassle-free access with a hinged cabinet
- Easily install your equipment with adjustable mounting rails
- Secure your mission-critical equipment with a locked enclosure
- Maximize compatibility by switching the mounting rails between square cage nut holes or tapped 12-24 holes
- 1U shelf and hook-and-loop cable tie included
HARDWARE
Fan Options Four Optional Fans: 120 mm
Frame Type Enclosed Cabinet
Front Door Construction Steel Mesh
Front Door Features Secure Key Lock with Reversible and Removable Front Door
Industry Standards EIA/ECA-310-E
Mounting Hole Types Square (For Cage Nut)
Threaded Hole
MountingRail Profile L-Shape
Rack Type 4-Post
Rear DoorConstruction Steel
Side PanelConstruction SteelMesh
Side PanelFeatures Secure Key Lock with Removable Side Panels
Special Features AdjustableMounting Rails
Built-in Cable Management
Grounding Lug(s)
Ships Fully Assembled
U-Markings
Wall-Mountable
U Height 12U
Wallmountable Yes
PERFORMANCE
Weight Capacity 198.9 lb [90 kg]
SPECIAL NOTES / REQUIREMENTS
Note Includes CABSHELFV1U and 2 pairs of keys
PHYSICAL CHARACTERISTICS
Color Black
Rear Door Features Secure Key Lock
PRODUCT MEASUREMENTS
Internal Depth 25.7 in [65.2 cm]
Internal Width 23.4 in [59.5 cm]
Maximum Mounting Depth 19.7 in [50 cm]
Minimum Mounting Depth 2.4 in [6 cm]
Product Height 25.2in [64 cm]
Product Length 25.8 in [65.5 cm]
Product Width 24 in [61 cm]
Weight of Product 82.7 lb [37.4 kg]
PACKAGING INFORMATION
Flat Pack (Assembly Required) Yes
Package Height 28.3 in [72 cm]
Package Length 26.6 in [67.5 cm]
Package Width 28.4 in [72.2 cm]
Shipping (Package) Weight 82.7 lb [37.4 kg]
WHAT'S IN THE BOX
Included in Package
1 - wall-mount enclosure
1 - 1U shelf
1 - roll of hook-and-loop fastener
50 - 12-24 cage nuts
50 - 12-24 screws
2 - door keys
2 - side panel keys
1 - instruction manual
